CFS 12
CFS® is a comprehensive general-purpose cold-formed steel componentdesign tool that performs calculations according to the AISI 2016 Editionof the North American Specification for the Design of Cold-Formed SteelStructural Members (S100-16), and the 2002 Edition of the ASCE Specification for theDesign of Cold-Formed Stainless Steel Structural Members (ASCE-8-02).
Cfs 9.0 Software Free
System Requirements
- Windows Vista, 7, 8, 8.1, 10 (32-bit or 64-bit)
- Microsoft.NET Framework 4.5
Specifications Supported
- AISI S100-16/S1-18 - ASD, LRFD, LSD
- AISI S100-16 - ASD, LRFD, LSD
- AISI S100-12 - ASD, LRFD, LSD
- AISI S100-07/S2-10 - ASD, LRFD, LSD
- AISI S100-07 - ASD, LRFD, LSD
- AISI 2004 - ASD, LRFD, LSD
- AISI 2001 - ASD, LRFD, LSD
- AISI 1999 - ASD and LRFD
- ASCE 8-02 - ASD and LRFD (stainless steel)
Section Versatility
The Section Wizard makes it quick and easy to create the geometryfor common shapes and the graphical interface allows you to createvirtually any cold-formed steel shape, including closed shapes,built-up sections, stiffeners, and elements with holes. You may choose froma long list of predefined carbon and stainless steel materials,or customize the material properties as needed. Additionally,several libraries are provided for commonly available componentshapes in the industry. Section geometry can imported and exportedusing DXF.
Quick Design
The CFS Quick Design tool makes design checks for industry standardshapes very fast and easy. It will even optimize the section thickness,flange size, and yield stress to meet your design requirements. And ifyou need to investigate the design in more detail, simply create thefull analysis problem with a single click.
Analysis Wizard
The Analysis Wizard assists in the creation of a variety of designproblems such as beam-columns, continuous beams, and multi-span beams withlaps. Analysis problems consist of members, supports, braces, loadingsand load combinations. Transverse loads may be concentrated ordistributed, and applied at any angle, thus producing biaxialbending. Axial loads may include eccentricities which induce additionalmoments. You can display and print diagrams for reactions, shears,moments, and deflection, including envelope diagrams for all loadcombinations.
Computations
- Full, net, and effective section properties using exact integrations
- Strengths for compression, tension, moments, shears, bimoment, and web-crippling
- Strength increase from cold work of forming
- Member checks for combined axial/bending, bending/shear, bending/torsion, and bending/web-crippling
- Calculation trace available for additional details
- Messages given for exceeded limits such as w/t, D/t, KL/r, etc.
- Elastic buckling anaylsis using finite strip method
- Complete documentation included as an integrated help file
Elastic Buckling Analysis
A powerful feature of CFS is the elastic bucklinganalysis of any cross-section using the finite strip method. Someshapes may be subject to a mode of buckling where the section distorts.This tool helps the engineer to utilize the Direct Strength Method(DSM) according to the AISI Specification.
Light vs. Full License
CFS is free to download and install. Without the purchase of a full license, the application will runin 'light' mode with a reduced set of features and limitations on section complexity.This mode is ideal for educational use and will give you a feel for what the fullCFS software has to offer. You may then choose to purchase a license forthe full version CFS. Here is a comparison between the full and light modes.
| Description | Light | Full |
| Features | ||
| Maximum elements per part | 5 | 254 |
| Maximum parts per section | 1 | 254 |
| Holes in elements | ✓ | |
| Carbon steel materials | ✓ | ✓ |
| Stainless steel materials | ✓ | |
| Custom material properties | ✓ | |
| Access section libraries | ✓ | ✓ |
| Create section libraries | ✓ | |
| Import geometry from DXF files | ✓ | |
| Save geometry to DXF files | ✓ | |
| Calculations | ||
| Full section properties | ✓ | ✓ |
| Net section properties | ✓ | |
| Effective section properties | ✓ | ✓ |
| Strength increase from cold working | ✓ | |
| Inelastic reserve strength | ✓ | |
| Detailed torsion properties | ✓ | |
| AISI - ASD, LRFD, and LSD methods | ✓ | ✓ |
| Direct Strength Method (DSM) | ✓ | ✓ |
| Fully braced strengths | ✓ | ✓ |
| Axial/Bending member checks | ✓ | ✓ |
| Bending/Shear member checks | ✓ | ✓ |
| Bending/Web-crippling checks | ✓ | ✓ |
| Bending/Torsion member checks | ✓ | |
| Quick Design checks | ✓ | ✓ |
| Elastic buckling analysis | ✓ | |
| Generate DSM buckling values | ✓ | |
| Analysis Module | ||
| Single member | ✓ | ✓ |
| Multiple spans | ✓ | |
| Multiple members | ✓ | |
| Transverse loads, moments, and axial loads | ✓ | ✓ |
| Numerous support and bracing options | ✓ | ✓ |
| ASD, LRFD, and LSD load combinations | ✓ | ✓ |
| Diagrams for shear, moment, and deflection | ✓ | ✓ |
| Diagrams for torque, bimoment, and twist | ✓ | |
| Locations of critical check points | ✓ | ✓ |
CFS12 Automation Module
For users of CFS 12, this optional software component providesthe full computational engine of the CFS application for customizedautomation of cold-formed steel calculations in your own applications.There are numerous ways to use this library, including spreadsheetmacros, creation of spreadsheet tables, automated design checks usingexternal analysis data, and even full-fledged structure design automation.
System Requirements
- Windows Vista, 7, 8, 8.1, 10 (32-bit or 64-bit)
- Microsoft.NET Framework 4.5
- Development environment supporting COM or .NET 4.5
- CFS 12 software installed and licensed (network or single-user, with automation)
Additional Info
The calculation methods in CFS12 can use existing section files orsection libraries created using CFS, or you can define new sections 'on the fly'to analyze. These methods perform operations such as retrievalof section information, computation of gross section properties,net section properties, effective section properties, fully bracedstrengths, and design checks for axial, bending, shear, web-crippling,combined axial/bending, combined shear/bending, and combined web-crippling/bending.
The CFS12 module includes complete documentation of the objects,methods, and properties, and some sample code to get you started. Thisdocumentation is available from our Download page.
This product is incorporated into the structuralanalysis application VisualAnalysis for performing cold-formed steeldesign checks on 3D structures. The VisualAnalysis software isoffered by IntegratedEngineering Software.
